36" Monogram Stainless Steel Professional Hood - ZV36SSJSS
Literature
Book an Appointment with a Monogram Appliance Expert!
Caplan's can help choose the right products for your home. Request an appointment to visit our showrooms and be inspired.
Caplan’s Picks
Features
510 CFM vertical exhaust
2 halogen lamps with 4 lighting levels
Infrared warming lamp(s)
Utensil racks
Removable grease trays
Dishwasher-safe removable baffle stainless steel filters
Variable speed fan control
| Inputs & Outputs | |
|---|---|
| Baffle Stainless Steel Filters | 2 |
| Cooktop Lighting | 2, Halogen |
| Damper in Transition | Yes |
| Double Wall Construction | Yes |
| Exhaust Options | 10" Round Duct |
| Grease Tray | 2 |
| Infrared Warming Lamps | 1 |
| Lighting Levels | 4 |
| Recirculating Capable | No |
| Removable Filter | Yes |
| Required Duct Size | 10-in. Round |
| Utensil Rod | Brushed Stainless Steel |
| Variable Speed Fan | Yes |
| Vertical Exhaust Blower Rating (CFM) | 510 |
| Welded / Finished Seams | Yes |
| CFM/ Sones Rating | 510/8.0 |
| Specification | |
| Working Speed CFM/Sones | 230/3.0 |
| Appearance | |
| Color Appearance | Stainless Steel |
| Design Style | Professional |
| Exterior Design | Straight Sides |
| Weights & Dimensions | |
| Approximate Shipping Weight | 68.0 |
| Cabinet Width | 36.0 |
| Net Weight | 51.0 |
| Overall Depth | 25.0 |
| Overall Height | 18.0 |
| Overall Width | 36.0 |
| Power / Ratings | |
| Amps at 110V | 6.5 |
| Accessories | |
| Optional 12" Duct Cover | ZX36DC12J |
| Optional 6" Duct Cover | ZX36DC6J |
| WARRANTY | |
| Labor Warranty | Limited 1-year entire appliance |
| Parts Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
