30" GE 5.0 Cu. Ft. Freestanding Electric Self Cleaning Range - JCB630DKWW
30" GE 5.0 Cu. Ft. Freestanding Electric Self Cleaning Range - JCB630DKWW
Caplan's can help choose the right products for your home. Request an appointment to visit our showrooms and be inspired.
Caplan’s Picks
2 Ribbon, 8" Heating Elements
With ribbon heating elements, the heat comes from brightly glowing elements positioned beneath the smooth surface. Even heat is directed straight up to the pan for high speed heat-up. Provides a quick "on" with a bright visual response.
Quick Clean Storage Drawer.
The frameless design allows this handy storage drawer to roll out completely without any obstruction. Whether you mop, sweep, or vacuum, every inch of your floor comes completely clean.
Glass-Ceramic Cooktop.
The cooktop is made with a specially engineered ceramic glass that has an amazing resistance to both stains and impact.
Hot Surface Indicator Lights
Heating Elements have a "hot surface" indicator light to let you know when the element is too hot to touch (it continues to work if the element has been turned off.)
Self-Clean Oven
Self-clean allows you to spare yourself from the trouble and effort it takes to scrub the oven interior. The oven does all the work!
Super Large Oven Capacity
Provides an impressively large oven interior for cooking more dishes and large meals at one time.
| Inputs & Outputs | |
|---|---|
| Certified Sabbath Mode | Yes |
| Auto Self-Clean | Yes |
| Auto Oven Shut-Off with Override | Yes |
| Audible Preheat Signal | Yes |
| 4 Pass Broil Element | 3410 watt |
| 4 Pass Bake Element | 2585 watt |
| Clock & Kitchen Timer | Yes |
| Cooktop Type | Smoothtop |
| Digipad | Yes |
| Dishwasher Safe Knobs | Yes |
| Dual Element Bake | Yes |
| Electronic Oven Control | Yes |
| Element - Left Front | 6" 1500W |
| Element - Left Rear | 8" 2000W |
| Element - Right Front | 8" 2000W |
| Element - Right Rear | 6" 1500W |
| Fuel Type | Electric |
| Glass-Ceramic Cooktop | Patterned White on Black Glass |
| Hi / Low Broil | Yes |
| Hot Surface | 1 |
| Infinite Heat Controls | Yes |
| One-Piece Upswept Cooktop | Porcelain Enamel |
| Outlets | None |
| Oven Interior Light | Yes |
| Oven Rack Positions | 6 |
| Oven Racks | 2 Chrome |
| Oven Temperature Display | Digitemp |
| Oven Type / Cleaning | Self-Clean |
| QuickSet Controls | QuickSet III |
| Removable Full-Width Storage Drawer | White |
| Start Pad | Yes |
| Surface Unit On | 1 |
| Total Indicator Lights | 2 |
| Capacity | |
| Oven Capacity | 5.0 |
| Appearance | |
| Window | Big ClearViewTM |
| Textured Steel Side Panels | White |
| Oven Door Type | White Glass |
| Handle Style | VBL |
| Easy Level System | 4 Leveling Legs |
| Colour Appearance | White on White |
| Backguard Type | Steel, White |
| Power & Ratings | |
| Amps @ 240V/208V | 40 |
| EnerGuide Rating (kWh/year) | 495 |
| KW Rating at 208V | 7.9 |
| KW Rating at 240V | 10.5 |
| Weights & Dimensions | |
| Approximate Shipping Weight (lbs.) | 175 |
| Depth with Door Open (in.) | 46 1/4 |
| Overall Depth (in.) | 26 1/4 |
| Overall Depth Including Handle (in.) | 27 3/4 |
| Overall Height (in.) | 47-3/4 |
| Overall Width (in.) | 29-7/8 |
